All‑Road Versatility. Endurance Comfort. The UK‑made Signature Echelon — crafted from Grade 9 titanium for fast, responsive riding mile after mile.
The Inspiration
The Echelon has been a cornerstone of our Signature lineup, evolving over the years to meet the demands of riders seeking a handcrafted, high-performance titanium road bike made in the UK.
Now refined as a dedicated All-Road model, the Echelon is designed to be your go-to ride for year-round versatility. By accommodating wider tyres and full mudguard compatibility, it seamlessly adapts to varying road conditions and seasons—from fast-paced summer rides to long winter training miles.
This evolution highlights our commitment to crafting exceptional, do-it-all road machines that combine refined titanium engineering, all-day comfort, and uncompromising performance. The Echelon All-Road is built to handle whatever the road throws your way, ensuring a ride that is fast, smooth, and endlessly rewarding.
- Frame Material Custom butted, size specific, grade 9 3Al/2.5V titanium
- Frame Finish Satin bead-blast finish with brushed logos
- Headtube CNC machined 44mm
- Bottom Bracket Custom machined Ti T47 68mm
- Dropouts Paragon, thru-axle
- Hanger Enigma Type 2
- Brake Mount 160 front / 140 rear flat mount
- Axle Size 12mm x 142mm bolt-thru
- Tyre Clearance 700c x 35mm
- Cable Routing Internal via custom entry ports
- Front Derailleur 34.9mm Band On
- Seat Tube External 34.9mm
- Seatpost 31.6mm or 27.2 with shim
- Headset Integral ZS44 Upper / EC44 Lower
